IN STOCK SHIPPING NOW!
Designed for those who seek the top of the podium, and optimized for the unafraid, uncompromising athlete. Whether you’re tackling your toughest competitors, aiming to be the first to cross the finish line, or racing for a pro card, we’ve got you covered with a wheel aerodynamically optimized with your choice of 25, 28, or 32mm tires and a wide 21mm internal rim width for crushing rolling resistance and enhancing stability. Be your Fastest and have a record setting day.
| FLO 77 AS Disc | Front | Rear |
|---|---|---|
| Wheel Weight | 828g* | 975g* |
| Rim Depth | 76.6mm | 76.6mm |
| Internal Rim Width | 21.0mm | 21.0mm |
| Brake Track Width | 28.0mm | 28.0mm |
| Max Rim Width | 28.4mm | 28.4mm |
| Tubeless Compatible | Yes | Yes |
| Carbon Fiber | Matte UD** | Matte UD** |
| Rim Type | 700c Clincher | 700c Clincher |
| Brake Type | Centerlock Disc | Centerlock Disc |
| Spokes | Sapim CX-Ray | Sapim CX-Ray |
| Spoke Color | Black | Black |
| Spoke Count | 24 | 24 |
| Spoke Lacing | 2X - Drive & Non-Drive Side | 2X - Drive & Non-Drive Side |
| Hub | FLO Vortex 3 | FLO Vortex 3 |
| Bearings | 6900 Japanese EZO | 6902 Japanese EZO |
| Freehub Options | - | Shimano/SRAM 10/11, XDR, Campy |
| Recommended Tire | Continental GP 5000 | Continental GP 5000 |
| Aero Optimized Tire Size | 25mm, 28mm, 32mm | 25mm, 28mm, 32mm |
| Minimum Tire Size | 23mm | 23mm |
| Recommended Tire Pressure | See Tire Pressure Chart Below | See Tire Pressure Chart Below |
Getting Started
To learn how to set-up and install your new FLO Wheels check out our How To page.
Maintenance
Freehubs - Service freehubs every 1,500 miles
Check the following items every six months:
Wheel Cleaning
When cleaning FLO Wheels, we recommend Dawn soap and water or acetone. Do not use oil based products like GooGone.
Optimize your tire pressure for your weight, riding surface, tire casing width, and internal rim width by using the tire pressure recommendation table below. The pressures listed are starting recommendations. We suggest experimenting with your tire pressure to find what is the fastest for you and the roads you ride. Remember, being slightly lower is better than being slightly higher.
Follow these steps to use the table:
| Bike + Rider Weight (lbs) | Bike + Rider Weight (kg) | Recommended Tire Pressure (psi) | |||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheel Model FLO 49 AS, FLO 64 AS, FLO 77 AS 21mm Internal Rim Width |
Wheel Model FLO G700, FLO G650 25mm Internal Rim Width |
||||||||||||||||||||||||
| Smooth Pavement | Medium Pavement | Rough Pavement | Packed Gravel | Packed Gravel | Course Gravel | Pavement | |||||||||||||||||||
| 25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
32-35mm Tire |
37-40mm Tire |
42-45mm Tire |
47-50mm Tire |
32-35mm Tire |
37-40mm Tire |
42-45mm Tire |
47-50mm Tire |
32-35mm Tire |
37-40mm Tire |
42-45mm Tire |
47-50mm Tire |
||
| 100 | 45 | 80.0 | 75.0 | 70.0 | 76.0 | 71.0 | 66.0 | 70.0 | 65.0 | 62.0 | 60.0 | 55.0 | 52.0 | 46.0 | 35.0 | 29.0 | 24.0 | 42.0 | 32.0 | 26.0 | 20.0 | 58.0 | 40.0 | 33.0 | 28.0 |
| 110 | 50 | 81.0 | 76.0 | 71.0 | 77.0 | 72.0 | 67.0 | 70.9 | 65.9 | 62.9 | 60.8 | 55.8 | 52.8 | 46.8 | 35.8 | 29.8 | 24.8 | 42.7 | 32.7 | 26.7 | 20.7 | 59.0 | 41.0 | 34.0 | 29.0 |
| 120 | 54 | 82.0 | 77.0 | 72.0 | 77.9 | 72.9 | 67.9 | 71.8 | 66.8 | 63.8 | 61.5 | 56.5 | 53.5 | 47.5 | 36.5 | 30.5 | 25.5 | 43.3 | 33.3 | 27.3 | 21.3 | 59.9 | 41.9 | 34.9 | 29.9 |
| 130 | 59 | 83.0 | 78.0 | 73.0 | 78.9 | 73.9 | 68.9 | 72.7 | 67.7 | 64.7 | 62.3 | 57.3 | 54.3 | 48.3 | 37.3 | 31.3 | 26.3 | 44.0 | 34.0 | 28.0 | 22.0 | 60.9 | 42.9 | 35.9 | 30.9 |
| 140 | 64 | 84.0 | 79.0 | 74.0 | 79.8 | 74.8 | 69.8 | 73.6 | 68.6 | 65.6 | 63.0 | 58.0 | 55.0 | 49.0 | 38.0 | 32.0 | 27.0 | 44.6 | 34.6 | 28.6 | 22.6 | 61.8 | 43.8 | 36.8 | 31.8 |
| 150 | 68 | 85.0 | 80.0 | 75.0 | 80.8 | 75.8 | 70.8 | 74.5 | 69.5 | 66.5 | 63.8 | 58.8 | 55.8 | 49.8 | 38.8 | 32.8 | 27.8 | 45.3 | 35.3 | 29.3 | 23.3 | 62.8 | 44.8 | 37.8 | 32.8 |
| 160 | 73 | 86.0 | 81.0 | 76.0 | 81.7 | 76.7 | 71.7 | 75.4 | 70.4 | 67.4 | 64.5 | 59.5 | 56.5 | 50.5 | 39.5 | 33.5 | 28.5 | 45.9 | 35.9 | 29.9 | 23.9 | 63.7 | 45.7 | 38.7 | 33.7 |
| 170 | 77 | 87.0 | 82.0 | 77.0 | 82.7 | 77.7 | 72.7 | 76.3 | 71.3 | 68.3 | 65.3 | 60.3 | 57.3 | 51.3 | 40.3 | 34.3 | 29.3 | 46.6 | 36.6 | 30.6 | 24.6 | 64.7 | 46.7 | 39.7 | 34.7 |
| 180 | 82 | 88.0 | 83.0 | 78.0 | 83.6 | 78.6 | 73.6 | 77.2 | 72.2 | 69.2 | 66.0 | 61.0 | 58.0 | 52.0 | 41.0 | 35.0 | 30.0 | 47.2 | 37.2 | 31.2 | 25.2 | 65.6 | 47.6 | 40.6 | 35.6 |
| 190 | 86 | 89.0 | 84.0 | 79.0 | 84.6 | 79.6 | 74.6 | 78.1 | 73.1 | 70.1 | 66.8 | 61.8 | 58.8 | 52.8 | 41.8 | 35.8 | 30.8 | 47.9 | 37.9 | 31.9 | 25.9 | 66.6 | 48.6 | 41.6 | 36.6 |
| 200 | 91 | 90.0 | 85.0 | 80.0 | 85.5 | 80.5 | 75.5 | 79.0 | 74.0 | 71.0 | 67.5 | 62.5 | 59.5 | 53.5 | 42.5 | 36.5 | 31.5 | 48.5 | 38.5 | 32.5 | 26.5 | 67.5 | 49.5 | 42.5 | 37.5 |
| 210 | 95 | 91.0 | 86.0 | 81.0 | 86.5 | 81.5 | 76.5 | 79.9 | 74.9 | 71.9 | 68.3 | 63.3 | 60.3 | 54.3 | 43.3 | 37.3 | 32.3 | 49.2 | 39.2 | 33.2 | 27.2 | 68.5 | 50.5 | 43.5 | 38.5 |
| 220 | 100 | 92.0 | 87.0 | 82.0 | 87.4 | 82.4 | 77.4 | 80.8 | 75.8 | 72.8 | 69.0 | 64.0 | 61.0 | 55.0 | 44.0 | 38.0 | 33.0 | 49.8 | 39.8 | 33.8 | 27.8 | 69.4 | 51.4 | 44.4 | 39.4 |
| 230 | 104 | 93.0 | 88.0 | 83.0 | 88.4 | 83.4 | 78.4 | 81.7 | 76.7 | 73.7 | 69.8 | 64.8 | 61.8 | 55.8 | 44.8 | 38.8 | 33.8 | 50.5 | 40.5 | 34.5 | 28.5 | 70.4 | 52.4 | 45.4 | 40.4 |
| 240 | 109 | 94.0 | 89.0 | 84.0 | 89.3 | 84.3 | 79.3 | 82.6 | 77.6 | 74.6 | 70.5 | 65.5 | 62.5 | 56.5 | 45.5 | 39.5 | 34.5 | 51.1 | 41.1 | 35.1 | 29.1 | 71.3 | 53.3 | 46.3 | 41.3 |
| 250 | 113 | 95.0 | 90.0 | 85.0 | 90.3 | 85.3 | 80.3 | 83.5 | 78.5 | 75.5 | 71.3 | 66.3 | 63.3 | 57.3 | 46.3 | 40.3 | 35.3 | 51.8 | 41.8 | 35.8 | 29.8 | 72.3 | 54.3 | 47.3 | 42.3 |
| 260 | 118 | 96.0 | 91.0 | 86.0 | 91.2 | 86.2 | 81.2 | 84.4 | 79.4 | 76.4 | 72.0 | 67.0 | 64.0 | 58.0 | 47.0 | 41.0 | 36.0 | 52.4 | 42.4 | 36.4 | 30.4 | 73.2 | 55.2 | 48.2 | 43.2 |
| 270 | 122 | 97.0 | 92.0 | 87.0 | 92.2 | 87.2 | 82.2 | 85.3 | 80.3 | 77.3 | 72.8 | 67.8 | 64.8 | 58.8 | 47.8 | 41.8 | 36.8 | 53.1 | 43.1 | 37.1 | 31.1 | 74.2 | 56.2 | 49.2 | 44.2 |
Optimize your tire pressure for your weight, riding surface, tire casing width, and internal rim width by using the tire pressure recommendation tables below. The pressures listed are starting recommendations. We suggest experimenting with your tire pressure to find what is the fastest for you and the roads you ride. Remember, being slightly lower is better than being slightly higher.
Follow these steps to use the table:
| Bike + Rider Weight (lbs) | Bike + Rider Weight (kg) | Recommended Tire Pressure (psi) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheel Model FLO 49 AS, FLO 64 AS, FLO 77 AS 21mm Internal Rim Width |
|||||||||||||
| Smooth Pavement | Medium Pavement | Rough Pavement | Packed Gravel | ||||||||||
| 25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
25-27mm Tire |
28-30mm Tire |
32-35mm Tire |
||
| 100 | 45 | 80.0 | 75.0 | 70.0 | 76.0 | 71.0 | 66.0 | 70.0 | 65.0 | 62.0 | 60.0 | 55.0 | 52.0 |
| 110 | 50 | 81.0 | 76.0 | 71.0 | 77.0 | 72.0 | 67.0 | 70.9 | 65.9 | 62.9 | 60.8 | 55.8 | 52.8 |
| 120 | 54 | 82.0 | 77.0 | 72.0 | 77.9 | 72.9 | 67.9 | 71.8 | 66.8 | 63.8 | 61.5 | 56.5 | 53.5 |
| 130 | 59 | 83.0 | 78.0 | 73.0 | 78.9 | 73.9 | 68.9 | 72.7 | 67.7 | 64.7 | 62.3 | 57.3 | 54.3 |
| 140 | 64 | 84.0 | 79.0 | 74.0 | 79.8 | 74.8 | 69.8 | 73.6 | 68.6 | 65.6 | 63.0 | 58.0 | 55.0 |
| 150 | 68 | 85.0 | 80.0 | 75.0 | 80.8 | 75.8 | 70.8 | 74.5 | 69.5 | 66.5 | 63.8 | 58.8 | 55.8 |
| 160 | 73 | 86.0 | 81.0 | 76.0 | 81.7 | 76.7 | 71.7 | 75.4 | 70.4 | 67.4 | 64.5 | 59.5 | 56.5 |
| 170 | 77 | 87.0 | 82.0 | 77.0 | 82.7 | 77.7 | 72.7 | 76.3 | 71.3 | 68.3 | 65.3 | 60.3 | 57.3 |
| 180 | 82 | 88.0 | 83.0 | 78.0 | 83.6 | 78.6 | 73.6 | 77.2 | 72.2 | 69.2 | 66.0 | 61.0 | 58.0 |
| 190 | 86 | 89.0 | 84.0 | 79.0 | 84.6 | 79.6 | 74.6 | 78.1 | 73.1 | 70.1 | 66.8 | 61.8 | 58.8 |
| 200 | 91 | 90.0 | 85.0 | 80.0 | 85.5 | 80.5 | 75.5 | 79.0 | 74.0 | 71.0 | 67.5 | 62.5 | 59.5 |
| 210 | 95 | 91.0 | 86.0 | 81.0 | 86.5 | 81.5 | 76.5 | 79.9 | 74.9 | 71.9 | 68.3 | 63.3 | 60.3 |
| 220 | 100 | 92.0 | 87.0 | 82.0 | 87.4 | 82.4 | 77.4 | 80.8 | 75.8 | 72.8 | 69.0 | 64.0 | 61.0 |
| 230 | 104 | 93.0 | 88.0 | 83.0 | 88.4 | 83.4 | 78.4 | 81.7 | 76.7 | 73.7 | 69.8 | 64.8 | 61.8 |
| 240 | 109 | 94.0 | 89.0 | 84.0 | 89.3 | 84.3 | 79.3 | 82.6 | 77.6 | 74.6 | 70.5 | 65.5 | 62.5 |
| 250 | 113 | 95.0 | 90.0 | 85.0 | 90.3 | 85.3 | 80.3 | 83.5 | 78.5 | 75.5 | 71.3 | 66.3 | 63.3 |
| 260 | 118 | 96.0 | 91.0 | 86.0 | 91.2 | 86.2 | 81.2 | 84.4 | 79.4 | 76.4 | 72.0 | 67.0 | 64.0 |
| 270 | 122 | 97.0 | 92.0 | 87.0 | 92.2 | 87.2 | 82.2 | 85.3 | 80.3 | 77.3 | 72.8 | 67.8 | 64.8 |
| Bike + Rider Weight (lbs) | Bike + Rider Weight (kg) | Recommended Tire Pressure (psi) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheel Model FLO G700, FLO G650 25mm Internal Rim Width |
|||||||||||||
| Packed Gravel | Course Gravel | Pavement | |||||||||||
| 32-35mm Tire |
37-40mm Tire |
42-45mm Tire |
47-50mm Tire |
32-35mm Tire |
37-40mm Tire |
42-45mm Tire |
47-50mm Tire |
32-35mm Tire |
37-40mm Tire |
42-45mm Tire |
47-50mm Tire |
||
| 100 | 45 | 46.0 | 35.0 | 29.0 | 24.0 | 42.0 | 32.0 | 26.0 | 20.0 | 58.0 | 33.0 | 33.0 | 28.0 |
| 110 | 50 | 46.8 | 35.8 | 29.8 | 24.8 | 42.7 | 32.7 | 26.7 | 20.7 | 59.0 | 34.0 | 34.0 | 29.0 |
| 120 | 54 | 47.5 | 36.5 | 30.5 | 25.5 | 43.3 | 33.3 | 27.3 | 21.3 | 59.9 | 34.9 | 34.9 | 29.9 |
| 130 | 59 | 48.3 | 37.3 | 31.3 | 26.3 | 44.0 | 34.0 | 28.0 | 22.0 | 60.9 | 35.9 | 35.9 | 30.9 |
| 140 | 64 | 49.0 | 38.0 | 32.0 | 27.0 | 44.6 | 34.6 | 28.6 | 22.6 | 61.8 | 36.8 | 36.8 | 31.8 |
| 150 | 68 | 49.8 | 38.8 | 32.8 | 27.8 | 45.3 | 35.3 | 29.3 | 23.3 | 62.8 | 37.8 | 37.8 | 32.8 |
| 160 | 73 | 50.5 | 39.5 | 33.5 | 28.5 | 45.9 | 35.9 | 29.9 | 23.9 | 63.7 | 38.7 | 38.7 | 33.7 |
| 170 | 77 | 51.3 | 40.3 | 34.3 | 29.3 | 46.6 | 36.6 | 30.6 | 24.6 | 64.7 | 39.7 | 39.7 | 34.7 |
| 180 | 82 | 52.0 | 41.0 | 35.0 | 30.0 | 47.2 | 37.2 | 31.2 | 25.2 | 65.6 | 40.6 | 40.6 | 35.6 |
| 190 | 86 | 52.8 | 41.8 | 35.8 | 30.8 | 47.9 | 37.9 | 31.9 | 25.9 | 66.6 | 41.6 | 41.6 | 36.6 |
| 200 | 91 | 53.5 | 42.5 | 36.5 | 31.5 | 48.5 | 38.5 | 32.5 | 26.5 | 67.5 | 42.5 | 42.5 | 37.5 |
| 210 | 95 | 54.3 | 43.3 | 37.3 | 32.3 | 49.2 | 39.2 | 33.2 | 27.2 | 68.5 | 43.5 | 43.5 | 38.5 |
| 220 | 100 | 55.0 | 44.0 | 38.0 | 33.0 | 49.8 | 39.8 | 33.8 | 27.8 | 69.4 | 44.4 | 44.4 | 39.4 |
| 230 | 104 | 55.8 | 44.8 | 38.8 | 33.8 | 50.5 | 40.5 | 34.5 | 28.5 | 70.4 | 45.4 | 45.4 | 40.4 |
| 240 | 109 | 56.5 | 45.5 | 39.5 | 34.5 | 51.1 | 41.1 | 35.1 | 29.1 | 71.3 | 46.3 | 46.3 | 41.3 |
| 250 | 113 | 57.3 | 46.3 | 40.3 | 35.3 | 51.8 | 41.8 | 35.8 | 29.8 | 72.3 | 47.3 | 47.3 | 42.3 |
| 260 | 118 | 58.0 | 47.0 | 41.0 | 36.0 | 52.4 | 42.4 | 36.4 | 30.4 | 73.2 | 48.2 | 48.2 | 43.2 |
| 270 | 122 | 58.8 | 47.8 | 41.8 | 36.8 | 53.1 | 43.1 | 37.1 | 31.1 | 74.2 | 49.2 | 49.2 | 44.2 |
Warranty Info
All wheels ship with a 2-year limited warranty. We want you to feel comfortable with your purchase. Please contact us if you have any issues with your wheels. If your wheels have material defects or issues with the workmanship we will take care of the problem. Issues such as misuse, crashes, or explosion of a wheel from compressor inflation are not covered. In the event you damage your wheel outside of warranty, please reach out to us as we can normally find a way to get you back on the road.
You can review our complete warranty here.
Shipping Info
USA
Standard Shipping: Ships in 1-3 Business Days. Delivers 2-7 Days After Shipment
USPS Priority Mail: Ships in 1-3 Business Days. Delivers 1-3 Days After Shipment
USPS Priority Mail Express: Ships in 1-3 Business Days. Delivers Overnight
International
Priority Mail International: Ships in 1-3 Business Days. Delivers 10-14 Days After Shipment
Priority Mail Express International: Ships in 1-3 Business Days. Delivers 5-10 Days After Shipment
Australia & Singapore
Priority Mail International: Ships in 1-3 Business Days. Delivers 10-14 Days After Shipment
Priority Mail Express International: Ships in 1-3 Business Days. Delivers 5-10 Days After Shipment
Import/Export
You are responsible to pay any import taxes or duties when importing FLO wheels from the USA. Please contact us for estimates.
Total power is calculated by adding the total watts consumed from aerodynamics and rolling resistance, with the goal to have your total power number as low as possible. A well-designed cycling wheel is optimized so you have the benefits of both–aerodynamics and low rolling resistance.
The graphs on the left show how many watts the FLO 77 AS Disc can save you over a standard bike wheel, Mavic Open Pro, and even a wheel that has only been optimized for aerodynamics, the 2016 FLO 90 Disc.
Continental GP 5000 tires in sizes 25mm, 28mm, and 32mm were used for optimization and testing. As you can see, 28mm tires on the FLO 77 AS Disc requires the fewest number of watts, making it the fastest tire for this wheel.
Learn more about Total Power.
Go further, faster with the FLO 77 AS Disc. This wheel was designed to save you watts by taking both aerodynamics and rolling resistance into consideration. Thanks to a drag-reducing aerodynamic profile that is optimized around a wide internal rim width, and designed to lower rolling resistance, the FLO 77 AS Disc ensures the watts you put into the pedals are not wasted spinning your wheels, but are used to move you forward. Explore the tabs to the right to learn more about how to shave off time and watts by choosing the FLO 77 AS Disc.
The goal of making a cycling wheel aerodynamic is to reduce the drag. Drag on a cycling wheel makes it more difficult to move the bike forward through the air, and consumes the watts you put into the pedals.
The FLO 77 AS Disc was designed to reduce the watts consumed by drag so the watts you put into the pedals move you forward. Be aero and be faster.
Learn more about Aerodynamics & Watts and our Wind Tunnel Testing.
The goal of lowering the rolling resistance for a cycling wheel is to make the wheel easier to roll. Rolling resistance occurs at the contact patch where your tire makes contact with the road surface. The higher the rolling resistance, the harder to move the bike forward, and the more watts wasted.
The FLO 77 AS Disc was designed with a wide internal rim width to shorten your contact patch, reduce the rolling resistance, and use the watts put into the pedals to move you forward. Be wider, be faster.
Learn more about Rolling Resistance & Impedance and our On Road Testing.
FLO 77 AS Disc
FLO Tubeless Tape
FLO Tubeless Vavle
Every FLO product is designed and engineered to make you faster but sold at an affordable price. With every purchase, a portion goes back to inspire future generations of cyclists through our Bike for a Kid program and help our planet through our One Wheel One Tree initiative. Most importantly, we are committed to you, the customer. We’ll meet you where you are on your journey, whether you’re a first time rider or a pro. We are here to provide you support. Save money, feel good, and become faster.
